S-series Single Coaxial Plug & Receptacle Set

The S-series single coaxial set adopts a push-pull self-locking mechanical design. It is specially engineered for coaxial cables and provides single-core (single-pole) coaxial electrical connection. Widely used in professional fields requiring high-reliability RF signal transmission. Available variants include right-angle plug, floating receptacle, double-nut receptacle, etc.

Online Consulting

File Download

Product Details

Related Parameters

Technical Data

General Model: S Series | TFA Plug | Single Coaxial PlugPart Number: TFA.1S.275.CLLD32Available Series: 00S, 0S, 1S, 2S, 3S, 4SApplication Environment: IndoorIP Rating: IP50Contact Count: 2~29 contactsMating Type: Push-pull self-lockingTermination Style: Solder, Crimp or PCB mount

Description: Straight plug, available with locating key (G) or key variants (A···M). Supplied with cable strain relief and boot-style rear cover.

General Model: S Series | ZRA Receptacle | Single Coaxial ReceptaclePart Number: ZRA.1S.275.CLLAvailable Series: 00S, 0S, 1S, 2S, 3S, 4SApplication Environment: IndoorIP Rating: IP50Contact Count: 2~29 contactsMating Type: Push-pull self-lockingTermination Style: Solder, Crimp or PCB mount

Description: ZGG fixed receptacle, nut mounting, available with locating key (G) or key variants (A...M & R), chassis rear mount.

Key Features

High-density mounting design, greatly saving installation space.
Quick push-pull self-locking system for easy operation and efficient connection.
Adopts stepped (half-moon) insert equipped with both male and female contacts.
Multi-contact options covering 2~32 pins to fully meet diverse application requirements.
Standard G-type locating key to ensure precise connector alignment.

Components

Housing: Pure brass substrate with chrome plating, delivering structural strength and corrosion resistance.
Male & female contacts: Pure copper material with gold plating to guarantee stable and reliable electrical conductivity.
Insulator insert: Injection-molded high-temperature engineering plastic with excellent insulation performance.
Cable boot: Molded soft plastic to effectively protect cables from external mechanical damage.
Rear metal nut: Enables multi-directional bending of wire harnesses for dynamic working scenarios.

Strategic Positioning

Backed by our mature full-chain system of R&D, manufacturing and sales, we provide professional, efficient customized one-stop electrical interconnection solutions for core industries including semiconductors, automation equipment, new energy equipment, humanoid robots, quadruped robots, unmanned aerial vehicles, and automotive manufacturing.
