B-THG 90° Angled Plug

The B-series right-angle plug adopts a 90° angled structure for space-constrained applications. It inherits the push-pull self-locking design for easy mating and anti-disengagement, with full shielding against electromagnetic interference. It enables neat cable routing without tangling and protects cables from bending damage. Featuring flexible mounting, it serves as a reliable interconnect option for precision instruments and compact equipment.

Online Consulting

File Download

Product Details

Related Parameters

Technical Data

General Model: B Series THG Plug | Right-Angle Plug Part Number: THG.1B.306.CLAD53 Series Code: 0B, 1B, 2B, 3B, 4B Application: Indoor IP Rating: IP50 Number of Contacts: 2~32 contacts Mating Method: Push-pull self-locking Termination Style: Solder, Crimp or PCB Mount Description: 90° right-angle plug with keying pin (G) or keying pin (A····M). Cable retention via cable clamp, available with boot-style backshell or metal nut.

Core Features

Fast push-pull self-locking system enables simple operation and efficient connection. Multi-contact options ranging from 2 to 32 contacts to meet diverse application demands. High-density mounting design greatly saves installation space. Standard G-type keying pins ensure precise mating alignment of connectors.

Component Construction

Shell: Pure copper substrate with chrome plating, delivering high mechanical strength and corrosion resistance. Pins / Sockets: Pure copper with gold plating to ensure stable and reliable electrical conductivity. Insulator: Injection-molded high-temperature resistant engineering plastic with excellent insulation property. Cable Boot: Molded flexible plastic, effectively protecting cables from external mechanical damage. Rear Metal Nut: Permits multi-directional bending of wire harnesses for dynamic working scenarios.

Strategic Positioning

Backed by our mature integrated R&D, manufacturing and sales system, we provide professional, efficient and customized one-stop electrical connection solutions for core industries including semiconductors, automation equipment, new energy equipment, humanoid robots, quadruped robots, bionic wolf robots, UAVs and automotive manufacturing.
