2P Plastic Straight Plug

Series 2P Straight Plug is made of high-hardness plastic, sturdy and lightweight, capable of withstanding steam sterilization. Adopting push-pull self-locking mechanical design, it enables quick one-hand operation with resistance to vibration and pulling. It is widely applied in medical, test & measurement and other equipment requiring high reliability and fast mating/unmating.

Online Consulting

File Download

Product Details

Related Parameters

Technical Data

Plug

General Model: P Series | PAG Plug | 2P Straight PlugPart No.: PAG.2P.308.GLAD62ZSeries Range: 0P, 1P, 2P, 3PApplication Environment: IndoorProtection Class: IP50Contact Count: 2–32 pinsMating Type: Push-Pull Self-LockingTermination: Solder, Crimp or PCB Connection

Description:PAG straight plug, locating pin (G) or locating keys (A····M), with cable clamp and boot-style back cover.

Color Options | Keying Options

Housing Color: Grey, black and white are available for better matching with cables. Component Color: (Back cover, nut, boot): Red, yellow, blue, green, orange, black, white, grey. Multiple colors for flexible combination. Keying System: Single key and multi-key configurations are adopted to realize anti-mismating function. Multi-key versions are differentiated by 40°, 60°, and 80° keying angles.

Core Features

High-density mounting design greatly saves installation space. Quick push-pull self-locking system for convenient operation and efficient connection. High-hardness plastic material, robust and lightweight, capable of withstanding steam sterilization. Multi-contact versions ranging from 2 to 32 pins to meet diverse application requirements. Standard G-type locating pin configuration ensures precise alignment of connectors.

Component Composition

Housing: Copper base with chrome plating, delivering structural strength and corrosion resistance. Contacts (Pins & Sockets): Solid copper with gold plating to guarantee stable and reliable electrical conductivity. Insulator Insert: Injection-molded high-temperature engineering plastic with excellent insulation performance. Rear Boot: Molded from flexible plastic to effectively protect cables against external damage. Rear Metal Nut: Allows multi-directional bending of wiring harnesses, suitable for dynamic working scenarios.

Strategic Positioning

Backed by our mature R&D, manufacturing and sales full-value chain system, we provide professional, efficient customized one-stop electrical connection solutions for core industries including semiconductors, automation equipment, new energy equipment, humanoid robots, quadruped robots (robot dogs & robot wolves), UAVs and automotive manufacturing.
