General Model: M12 | Overmolded Type | Unshielded | Male Connector

Application Environment: Indoor / Outdoor Ingress Protection: IP65 Number of Contacts: 2–17 contacts Mating Method: Thread twist locking Coding Options: Type A / Type B / Type D / Type X Termination Method: Screw-clamp / Wire soldering / PCB soldering Description: M12 threaded connector, overmolded type, metal housing, male connector, wire soldering termination

Contact us to obtain the connector technical datasheet.

Key Features

12mm opening dimension with compact size. 2~17 contacts, available with different coding types. High-density mounting design greatly saves installation space. Coding options: Type A, Type B, Type D and Type X. Version options: assembled type, overmolded type and panel mount type. Termination options: screw-clamp, wire soldering and PCB soldering. When male and female connectors are mated, the ingress protection rating ranges from IP65 to IP67 depending on the version.

Components

Metal housing: Pure copper substrate with nickel plating, offering structural strength and corrosion resistance. Plastic housing: Engineering polyamide (PA), featuring excellent mechanical properties and good environmental resistance. Contacts (pins & sockets): Pure copper with gold plating to ensure stable and reliable electrical conductivity. Insulator insert: Injection-molded high-temperature engineering plastic with outstanding insulation performance.
